Nabla Rail Fastening System / Railway Fastening System

Nabla fastening system is a safe and reliable railway fastening system that most widely used in Europe. In general, Nabla fastening system can be used in Tram, LRT, Metro, Main Line and High-Speed tracks. The special shape of the Nabla blade generates a dynamically stable toe load on the steel rails when the rail nut is torqued.

Components of Nabla Fastening System

The General Introduction

The Nabla Fastening System for ballasted track and slab track has the same key features that have made the Nabla system a success for decades.

It allows us to further enhance and simplify the installation operations and track maintenance.

The principle of Nabla Fastening System is to separate electrical insulation from the lateral support function by using two components assembled in the factory. By separating the two functions, it has been possible to use higher strength wear material in the lateral restraint block, thus increasing the life of the component and also providing means of lateral adjustment.

Features

1. Tensions to refusal for consistency of application force applied to the rail

2. Lateral adjustment in increments of 1.25 mm upto typical maximum +/- 10mm

3. Optimized for gauge widening in tight radius curves.

Parts

Photos for reference

Our main products:

1. Q: what information should we show if we need price?

A: 1. tree species;

2. size: length*width*thicknessl;

3. quantity;

4. we adopt oiled anti corrosion, if yours special, please mark it.

2.Q: what is anti-corrosion?

A: Using high temperature and pressure oiling corrosion technology.
Technology standards : GB9221-88

3. Q: payment terms?

A: 30% by T/T as deposit, the balance 70% before delivery.

4. Q: Validity Date?

A: 10~15 days in general. it will be showed in quotation.

5. Q: Mold fee?

A: if we have same mold, no mold fee;

if we make new mold with small quantity, client pay for it;

if we make new mold with large quantity, SuYu pay for it.

If you have any other models of rail/ rail fastener, welcome to contact me.

If you have any other models of rail/ rail fastener, welcome to contact me.

Contact: zy10@zyrail.com

Founded in 2013, located at No.199 Huanlou Road, development zone Kunshan city, we Suzhou Zhongyue Railway Material Co., Ltd. Is a leading and reputed manufacturer of qualified railway fasteners in China.

We are certified by ISO 9001:2008. We have a complete set of inspection equipments to strictly control the quality of each production procedure and make sure all the products reach the international standards and customers’ requirements.

ZY team is composed of high professional senior engineers, professional technicians and a group of highly experienced operation workers, this is the strong guarantee of our products quality. We have our own R&D team, after-sales service team and quality-assurance team with the most advance technology and management concepts.

With advanced technology, comprehensive testing facilities, excellent management team and powerful processing capacity, our products have been exported worldwide. After many times of inspections by BV, SGS，ABS etc, our products have been well recognized by our customers. We are qualified supplier of Kazakhstan Railway, Thailand Railway, Zambia Railway, Indonesia Railway, Malaysia Railway, Sweden Railway, New Zealand Railway, American Railway, Canada Railway etc, supplying all kinds of railway material to them for many years without any quality complaint.

We not only can produce according to International standards, customers’ drawings and samples, but also can provide design proposal by our own high standard R&D department.

With the principles of quality first and customers first, ZY Rail enjoys bulk popularity and high reputation at home and abroad, while having many customers all over the world. With powerful strength and broad vision, ZY rail is moving towards internationalization of enterprises.
